Kìm cắt cáp thủy lực TAC CPC-40A

TAC-CPC-40A

TAC/Taiwan

12 tháng

Kìm cắt cáp thủy lực TAC CPC-40A

Kìm cắt cáp thủy lực TAC CPC-40A

Hydraulic Cutting Tools

To cut the telephone cables, steel ropes, round bars, aluminum.
Hydraulic separate type of cutting tools: CPC-20B


CPC-20A

CPC-40A

CPC-55A

CPC-85A

CPC-100B

CPC-85B

CPC-20B

CPC-40B

CPC-55B

Characters:
1.It can be operated to cut on the electrical wire pole.
2.CPC-40A FRP insulated bar 20kv/5min.
3.It is specialized in cutting the separate type of steel wires and aluminum wires.
4.CPC-100B,85B.40B.55B.20B matched with pump of CTE-25AS or CP-700.
5.Packing has two: A. Canvas bag, B. Iron case.
6.Razors are manufactured with high carbon alloy steel, which is specialized in cutting steel, aluminum wires HRC 65¢X.
∗The blade of the razor is 45¢X and 5¢X; if cutting ACSR , please use to 5°

Figure for specification
A: direct typeB: separate type

Model

Output
(tons)

Weight
(kg)

Lenght
(mm)


Wire rope


Round bar

6x7
Hemp-
core

(mm)

6x12
Hemp-
core

(mm)

6x19
Hemp-
core

(mm)

Soft
Copper
Bar

(mm)

Soft
Alu-
minum
Bar
(mm)

Rein-
forcing
Bar

(mm)

Rein-
forcing
Bar

(mm)

CPC-20A

20

9.3

675

20

20

20

20

25

25

25

CPC-40A

6

6.5

630

12

12

12

12

12

12

12

CPC-55A

7

7.2

610

---

---

---

20

20

16

20

CPC-85A

4

9.2

705

---

---

---

---

---

---

---

CPC-20B

20

16

305

20

20

20

20

25

20

25

CPC-40B

6

4

310

22

25

20

20

20

16

20

CPC-55B

10

6

300

---

---

---

28

28

16

28

CPC-85B

4.5

6.5

456

---

---

---

---

---

---

---

CPC-100B

8.8

13.5

570

---

---

---

---

---

---

---



Model



Wire stands


Round bar

Bare Copper
Strands (mm)

Bare Aluminum Strands
(mm)

ACSR (mm)

1x7 Guy Steel Wire Strands
(mm)

1x19 Guy Steel Wire Strands (mm)

Tele- phone Gable CCP

Soft Aluminum Bar (mm)

Reinforcing
Bar (mm)

CPC-20A

32

32

32

32

32

---

---

32

CPC-40A

20

20

38

20

20

---

---

39

CPC-55A

24

50

50

28

20

---

---

50

CPC-85A

28

46

---

---

---

85

85

50

CPC-20B

32

32

35

20

20

---

---

41

CPC-40B

32

32

38

20

20

---

---

41

CPC-55B

50

50

50

15

20

---

---

50

CPC-85B

28

46

---

---

---

85

85

50

CPC-100B

42

46

---

---

---

---

100

70



CC-50B+A

CC-32B+A

Functions:

Figure for specification

Model

Name

Function

Output (Tons)

Weight (kg)

Cable Ø mm

Specification

Iron rope  Ø mm

CC-32B+A

Hydraulic cable cutting tool

D 32

4002

---

12

5

CC-50B+A

Hydraulic cable cutting tool

D 50

6302

---

12

6

    1. It can be operated to cut on the electrical wire pole.
    2. It is specialized in cutting the separate type of steel wires and aluminum wires.
    3. Razors are manufactured with high carbon alloy steel, which is specialized in cutting steel, aluminum wires HRC 65°.
    • The blade of the razor is 45° and 5°; if cutting ACSR, please use to 5°
    1. CC-32B, CC-50B the opener is 42mmO and 52mmO, easy to cutting operation in the distributed electricity tray.
    2. Available to high pressure PE.IV cables, phone wires, for cutting quickly.
    3. High carbon Tungsten alloy steel of razor is strong and heat treated HRC-65°.
    4. To match with pump CTE-25AS, CP-700 series.
    5. CC-32B, CC-50B hydraulic cylinder can be used with CC-104.
    • CSC-30B, CSC-52B can cut 9mm of iron.

Tên gọi khác của sản phẩm:
kìm cắt thủy lực TAC CPC-40A, kìm cắt cáp thủy lực TAC CPC-40A, kìm cắt cáp điện thủy lực TAC CPC-40A, kìm cắt dây điện thủy lực TAC CPC-40A, kem cat day dien thủy lực TAC CPC-40A
